Rocket science, star mapping vision algorithms and common sense for uncompromising probe card tester performance.

Building on European technology and design, to make it faster and easier for you. Make it better, make it easier: speed, accuracy, ergonomics. Use rocket science, star mapping vision algorithms and common sense for uncompromising performance.

Last forever
with Solid Diamond window. Even a sapphire window is subject to wear and scratches, just as the sapphire glass of your watch.

Stiffness, stability and light handling
with 2,3 inches carbon flip table and 600 lbs granite. 10,000 probes put on a lot of force. Still you want to measure the exact positions and not the flexing. A laminate carbon flip table is both extremely stiff and the lightest to handle. At 100kgf no more than 10 µm displacement. On top of a large block of granite we also get a maximum of stability.

Rework on the fly
with ergonomic flip table. Our system is developed with both Fabs and probe card manufacturers in mind. The probe under investigation can be flipped within seconds between rework and testing.

Level playing field
with motorised tilt & automatic motherboard adjustment. No two motherboards are the same. Once identified the automatic tilt levels the playing field.

Make a wrong reference file history
with RFID card recognition. Minimize possible operator errors. Automatically log card statistics in the database.

No time to waste
with embedded vision processors. Massive image data from the over 10000 pin measurement requires massive computing power. With FPGA DSP processors and smart camera's we can process images in real time on the camera, reducing overall data transfer overhead and reducing total test time. By incorporating a state of the art lighting control module and algorithm inside the camera low integration times are reached to increase the total frame rate to allow on the fly real-time probe card measurement. So calculation does not increase the test time.

The sky is the limit
with star mapping software. Theoretical informatics does provide useful solutions. We were happy to adopt the state of the art solution to pattern matching of the firmament to the mapping of our pin positions.

Advanced relay board
of 125 I/O, 3 standard plus additional voltage. Any relay driving voltage at your own taste.

A stiff base for uncompromising flexibility Workable and fast for the state of the art probe card analysis!
